TINI Q-G MINIATURE CONNECTORS
CONNECTORS & RECEPTACLES
?
FAX: 773 792-2129
* Please visit the product pages on our website for the most up-to-date product information
TINI Q-G ? MINIATURE CONNECTORS (continued)
37
TY(*)F AND TY(*)FPC RECEPTACLES
Female receptacle mounts in minimum
space from front or rear panel or chassis.
Terminals are solder lugs, Series
MOUNTING HOLE DETAIL
SERIES TY(*)F, TY(*)FPC
FRONT
REAR
MOUNTING
MOUNTING
COMBINED P.C. /PANEL
MOUNTING
TY(*)F, or P.C., Series TY(*)FPC. All
receptacles have separate ground lug.
RECOMMENDED P.C. BOARD LAYOUT
Part
Number
TY3F
TY3FPC
TY4F
TY4FPC
Insert
Contacts
3
3
4
4
Part
Number
TY5F
TY5FPC
Insert
Contacts
5
5
TYEF ESCUTCHEONS
TQG(*)F AND TQG(*)M
CONNECTOR INSERTS
Male and female inserts with 3, 4, 5
or 6 pins/ contacts. For replacement
(cord plugs only) or build-into
equipment, such as microphones,
transducers and instruments.
TBA(**) AUDIO ADAPTER
Trim escutcheons in seven colors for
use with Series TY(*)F and TY(*)FPC
receptacles, are recommended for rear
mount receptacles. Escutcheons must
be ordered separately.
Male Inserts
Part Number
? TQG3M
? TQG4M
? TQG5M
Insert Pins
3
4
5
3–6 pin male-to-male adapter is designed
for through-bulkhead or cable expansion
usage. Adapter is prewired pin 1 to pin 1,
pin 2 to pin 2, etc. Mounting nuts are
supplied for each threaded end. Panel
Part Number
? TYEF01
? TYEF02
Color
Red
Black
? TQG6M
Female Inserts
6
hole diameter required is .45"; maximum
panel thickness is .25" (6.35 mm).
? TYEF03
? TYEF04
? TYEF05
? TYEF08
? TYEF11
Green
Blue
White
Yellow
Gray
Part Number
? TQG3F
? TQG4F
? TQG5F
? TQG6F
Insert Contacts
3
4
5
6
Part Number
? TBA03
? TBA04
? TBA05
? TBA06
Insert Pins
3
4
5
6
? Available on special order only; contact Switchcraft for price and delivery.
DIMENSIONS ARE FOR REFERENCE ONLY
Inch
(mm)
SWITCHCRAFT, INC. 5555 N. Elston Ave. ? Chicago, IL 60630
